32D-Link DWR-116 User Manual
Section 3 - Conguration
Wi-Fi Protected Setup
Wi-Fi Protected Setup (WPS) System is a simplified method for
securing your wireless network during the “Initial setup” as well
as the “Add New Device” processes. The process is just as easy as
pressing a button for the Push-Button Method or correctly entering
an 8-digit code.
Enable/disable the Wi-Fi Protected Setup feature.
Shows the current PIN.
Create a random number that is a valid PIN. This
becomes the router’s PIN. You can then copy this
PIN to the user interface of the wireless client.
Select whether the router is the Enrollee or the
Registrar. If this is set to enrollee, the router will
try to connect to other devices. If it is set to registrar, other devices will try to connect to the router.
Displays the current state of WPS conguration. Clicking the Release button will disable any previously paired devices from connecting.
You will need to recongure WPS on those devices to connect them again.
This checkbox will disable pin authentication for WPS. You will have to use the push button on the router and the device you are
trying to connect in order to establish a WPS pairing.
Select whether the WPS authentication will use Pin code or push button method.
Displays the current state of the router’s WPS system.
The Trigger button acts like the physical WPS push button, and will search for devices nearby that are trying to establish a WPS
connection.
Enable:
AP PIN:
Generate New
PIN:
Config Mode:
Config Status:
Disable WPS-PIN
Method:
Config Method:
WPS Status:
Trigger:
Note: The DWR-116 has a WPS push button on the front panel that will activate WPS mode by pressing and holding the button
for approximately 6 seconds. The Wi-Fi LED will begin to ash rapidly when WPS mode has been activated.
