D-Link DWR-730 User Manual

12D-Link DWR-730 User Manual
Section 3 - Conguration
Home
Throughout the interface you will nd a menu bar at the top of the page which includes tabs for easy navigation, and a summary bar in the upper
right corner with a quick view of essential information.
The Home tab will return you the home page, where a summary of the system information is shown.
Click on this tab to start the setup wizard, which will guide you through the basic setup process.
The Internet tab gives you Internet setup and settings options.
The Network tab allows you to congure the network settings for your Local Area Network (LAN).
From the SMS tab you can view and send SMS messages via your mobile network.
The Wi-Fi tab allows you to congure your Wi-Fi network, as well as add new devices using WPS.
The Security tab allows you to congure rewall and security settings to protect your network from WAN-side
intrusions.
From this tab, you can manage the administrative conguration of your router, such as time and date, rmware,
language, and remote management.
Navigation
Home:
Wizard:
Internet:
Network:
SMS:
Wi-Fi:
Security:
Application:

D-Link DWR-730 Specifications

General

wireless standard	802.11g/b, compatible with 802.11n
Micro USB port	Yes
MicroSD slot	Yes
frequency bands	850/900/1800/1900 MHz
Power Class	4 (850/900 MHz), 1 (1800/1900 MHz)
frequency bands	850/1900/2100 MHz, 900/1900/2100 MHz
Power Class	3 (+24 dBm)
HSUPA Downlink	Up to 21.6 Mbps
HSUPA Uplink	Up to 5.76 Mbps
802.11n mode	Up to 150 Mbps
802.11g mode	6/9/11/12/18/24/36/48/54 Mbps
802.11b mode	1/2/5.5/11 Mbps
WEP	64/128-bit
WPA & WPA2	Yes
Built-in NAT	Yes
Built-in firewall	Yes
Type	Internal 3G and Wi-Fi antenna
Capacity	1500 mAh rechargeable
Indicators	SMS, Signal, Battery, Wi-Fi
Operating Temperature	-10 to 55 ˚C (14 to 131 ˚F)
Operating Humidity	10% to 90% (Non-condensing)
CE	Yes
FCC	Yes

Weight and Dimensions

Dimensions (L x W x H)	90 x 50 x 12 mm
