xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
191
Format
config cfm ma [<string 22> | ma_index <uint 1-4294967295>] md [<string 22> | md_index <uint
1-4294967295>] {vlanid <vlanid 1-4094> | mip [none | auto | explicit | defer] | sender_id [none |
chassis | manage | chassis_manage | defer] | ccm_interval [100ms | 1sec | 10sec | 1min | 10min]
| mepid_list [add | delete] <mepid_list1-8191>}(1)
Parameters
<string 22> - Specify the maintenance association name. The maximum length is 22 characters.
ma_index - Specifies the maintenance association index used.
<uint 1-4294967295> - Enter the maintenance association index value used here. This value
must be between 1 and 4294967295.
md - Specify the maintenance domain name.
<string 22> - Specify the maintenance domain name. The maximum length is 22 characters.
md_index - Specifies the maintenance domain index used.
<uint 1-4294967295> - Enter the maintenance domain index value used here. This value
must be between 1 and 4294967295.
vlanid - (Optional) Specify the VLAN Identifier. Different MAs must be associated with different
VLANs.
<vlanid 1-4094> - Specify the VLAN ID between 1 and 4094.
mip - (Optional) This is the control creation of MIPs.
none - Do not create MIPs.
auto - MIPs can always be created on any port in this MA if that port is not configured with an
MEP of that MA.
explicit - MIPs can be created on any ports in this MA only if the next existing lower level has
an MEP configured on that port, and that port is not configured with an MEP of this MA.
defer - Inherit the setting configured for the maintenance domain that this MA is associated
with. This is the default value.
sender_id - (Optional) This is the control transmission of the sender ID TLV.
none - Do not transmit the sender ID TLV. This is the default value.
chassis - Transmit the sender ID TLV with the chassis ID information.
manage - Transmit the sender ID TLV with the manage address information.
chassis_manage - Transmit the sender ID TLV with the chassis ID information and the
manage address information.
defer - Inherit the setting configured for the maintenance domain that this MA is associated
with. This is the default value.
ccm_interval - (Optional) Specify the CCM interval.
100ms - 100 milliseconds. Not recommended in CFM software mode.
1sec - One second.
10sec - Ten seconds. This is the default value.
1min - One minute.
10min - Ten minutes.
mepid_list - (Optional) Specify the MEPIDs contained in the maintenance association.
add - Add MEPID(s).
delete - Delete MEPID(s).
<mepid_list 1-8191> - Specify the MEPIDs contained in the maintenance association. The
range of the MEPID is 1 to 8191.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
