xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
202
Format
show cfm port <port> {level <int 0-7> | direction [inward | outward] | vlanid <vlanid 1-4094>}
Parameters
<port> - Specify the port number.
level - (Optional) Specify the maintenance domain level. If not specified, all levels are shown.
<int 0-7> - Specify the value between 0 and 7.
direction - (Optional) Specify the MEP direction.
inward - Specify inward facing MEP.
outward - Specify outward facing MEP.
vlanid - (Optional) Specify the VLAN identifier. If not specified, all VLANs are displayed.
<vlanid 1-4094> - Specify the VLAN ID between 1 and 4094.
Restrictions
None.
Example
To display a CFM port:
DGS-3420-28SC:admin#show cfm port 1
Command: show cfm port 1
MAC Address: 00-05-78-82-32-01
MD Name MA Name MEPID Level Direction VID
----------- ---------- ------- ------- --------- ---
op_domain op1 1 2 inward 2
cust_domain cust1 8 4 inward 2
serv_domain serv2 MIP 3 2
DGS-3420-28SC:admin#
14-17 cfm lock md
Description
This command is used to start/stop cfm management lock. This command will result in the MEP sends
a LCK PDU to client level MEP.
Format
cfm lock md [<string 22> | md_index <uint 1-4294967295>] ma [<string 22> | ma_index <uint 1-
4294967295>] mepid <int 1-8191> remote_mepid <int 1-8191> action [start | stop]
