xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide

601

Example

To display LLDP statistic information for port 1:

DGS-3420-28SC:admin#show lldp statistics ports 1

Command: show lldp statistics ports 1

Port ID : 1

---------------------------------------------

LLDPStatsTXPortFramesTotal : 0

LLDPStatsRXPortFramesDiscardTotal : 0

LLDPStatsRXPortFramesErrors : 0

LLDPStatsRXPortFramesTotal : 0

LLDPStatsRXPortTLVsDiscardedTotal : 0

LLDPStatsRXPortTLVsUnrecognizedTotal : 0

LLDPStatsRXPortAgeoutsTotal : 0

DGS-3420-28SC:admin#
