xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
817
the Q-in-Q profile and translated VLAN.
enable - Enable miss drop of ports.
disable - Disable miss drop of ports.
outer_tpid - Specify the outer-TPID of a port.
<hex 0x1-0xffff> - Specify the outer-TPID of a port.
use_inner_priority - Specify whether to use the priority in the C-VLAN tag as the priority in the
S-VLAN tag. By default, the setting is disabled.
enable - Specifies that the use of the inner priority will be enabled.
disable - Specifies that the use of the inner priority will be disabled.
add_inner_tag - Specify whether to add inner tag for ingress untagged packets. If set, the inner
tag will be added for the ingress untagged packets and, therefore, the packets that egress to
the NNI port will be double tagged.
<hex 0x1-0xffff> - Enter the inner tag value here.
disable - Specifies that only the s-tag will be added for ingress untagged packets.
add - Specifies to add a flow-based VLAN translation port’s QinQ rule.
delete - Specifies to delete a flow-based VLAN translation port’s QinQ rule.
vlan_translation_profile - Specifies the VLAN translation profile ID used.
<profile_id> - Enter the VLAN translation profile ID used here.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure ports 1 to 4 as NNI ports and set the TPID to 0x88A8:
DGS-3420-28SC:admin#config qinq ports 1-4 role nni outer_tpid 0x88a8
Command: config qinq ports 1-4 role nni outer_tpid 0x88a8
Success.
6-5 config qinq inner_tpid
Description
The command is used to configure the inner TPID of the system. The inner TPID is used to decide if
the ingress packet is c-tagged. Inner tag TPID is per system configurable. This command is used in
the ‘per-system’ TPID configuration.
Format
config qinq inner_tpid <hex 0x1-0xffff>
Parameters
<hex 0x1-0xffff> - Enter the Inner-TPID of the system used here.
