22
(see outside panel).
3. Remove the pressure switch hose from the sump.
4. Remove the clamp from the hose that connects the sump to the wash pump motor
hose.
Note: The sump clamping nut turns counterclockwise and may be difficult to remove. It may
be necessary to insert a screw driver or other tool between the clamping nut tabs to
enable you to apply sufficient torque to break the factory seal.
5. Remove the clamp from the hose that connects the sump to the drain pump assembly.
6. Open the dishwasher door and remove the lower basket (not shown).
7. Remove the filter assembly and micro-filter.
9. Remove the clamping nut.
switch
Clamp
Interconnect
Filter
assembly
Plane filter
To Next Page
