Daewoo DDW-M1212 User Manual

8
4. Remove the 3 screws and top mounting bracket.
5. Remove the dispenser from door assembly.
Removal and Replacement
1. Disconnect power.
2. Remove the filter assembly, upper and lower basket.
3. Remove the outer door.
4. Remove the 2 screws that connect the top panel 2 cover to the
dishwasher.
5. Take off the top panel and remove the 2 screws.
6. Remove the 2 screws and baseboard from the dishwasher.
7. Remove the 2 screws connected to left and right side baseboard.
Outside panel
Dispenser
Top panel

Daewoo DDW-M1212 Specifications

General

Brand	Daewoo
Model	DDW-M1212
Category	Dishwasher
Language	English
