12
a new set of star washers.
18. Remove the star washer from the dishwasher door hinge.
19. Remove the hinge pin from the dish- washer door hinge.
20. Repeat steps 13 through 20 to remove the left side door hinge assembly.
21. Remove the dishwasher door from the dishwasher.
22. Reverse the above procedure to install.
Removal and replacement
1. Drain up the water in the dishwasher, and disconnect the power supply.
2. Lay down the dishwasher on its back.
3. Remove the 4 screws.
4. Pull out the bottom board.
5. Reverse the above procedure to installć
Bottom Board
Caution: The star washer
is easily damaged and
To Next Page
