Dell C1765NFW User Manual

Faxing 283
Sending a Delayed Fax
The Delayed Start mode can be used to save scanned documents for transmission at a specified time in order to take
advantage of lower long distance rates.
1
Load the document(s) face up with top edge in first into the ADF.
OR
Place a single document face down on the document glass, and close the document cover.
For details about loading a document, see "Making Copies From the ADF" on page 235 or "Making Copies From
the Document Glass" on page 233.
2 Press the (Fax) button.
3 Enter the fax number of the remote fax machine using the numeric keypad, and then press the (Set) button.
You can also use speed dial or group dial numbers to specify the fax number. For more information, see "Automatic
Dialing" on page 289.
4 Press the button until Preferences is highlighted, and then press the ( Set ) button.
5 Press the button until Delayed Start is highlighted, and then press the (Set) button.
6 Press the button until On is highlighted, and then press the (Set) button.
7 Use the numeric keypad or press the or button to specify the start time, and then press the (Set)
button.
8 Configure the fax settings as necessary.
Settings such as resolution and contrast are available. For details about setting items, see "Setting Fax Options" on
page 281.
9 Ensure that Start Fax is highlighted, and then press the (Start) button.
Once the Delayed Start mode is activated, your printer stores all the documents to be faxed to its memory and
sends them at the specified time. After faxing in the Delayed Start mode is complete, the data in the memory is
cleared.
Sending a Fax from the Driver (Direct Fax)
You can send a fax directly from your computer by using the driver.
NOTE: Only black and white faxes can be sent using Direct Fax.
Send data via the Dell C1765nf
Color MFP FAX or Dell C1765nfw
Color MFP FAX driver
Sending machine (Dell
C1765nf/C1765nfw Color
Multifunction Printer)
Send fax
Receiving machine (fax
machine/multifunction
printer)

Dell C1765NFW Specifications

General

Duplex printing	No
Print technology	LED
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	16 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	15 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Fax polling	Yes
Flash memory	16 MB
Scan file formats	JPG, PDF, TIFF
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Print, Scan
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Connectivity technology	Wired & Wireless
Color all-in-one functions	copy, print
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	30000 pages per month
Number of print cartridges	4
Page description languages	GDI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2
Time to first copy (black, normal)	24 s
Time to first copy (color, normal)	40 s
Copy speed (black, normal quality, A4)	15 cpm
Copy speed (color, normal quality, A4)	12 cpm
Scan to	E-mail, FTP, USB
Scanner type	Flatbed & ADF scanner
Input color depth	24 bit
Maximum scan area	A4 / Letter (216 x 297) mm
Image formats supported	JPG, TIF
Maximum scan resolution	4800 x 4800 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 1200 DPI
Faxing	Mono faxing
Fax memory	2 MB
Modem speed	33.6 Kbit/s
Paper input type	Paper tray
Total input capacity	150 sheets
Total output capacity	100 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	15 sheets
Envelopes sizes	7 3/4, C5, DL
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Coated paper, Envelopes, Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Hagaki card, Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Product color	Black
Market positioning	Business
Display number of lines	4 lines
Display number of characters	20
Standard interfaces	USB 2.0
Wi-Fi standards	802.11b, 802.11g
Security algorithms	128-bit WEP, 64-bit WEP, WPA-AES, WPA-TKIP, WPS
Supported network protocols (IPv4)	TCP/IP, HTTP, Port 9100, LPD/LPR, BOOTP, DHCP, RARP, Auto IP, DNS, mDNS
Internal memory	128 MB
Processor frequency	295 MHz
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	2 W
Power consumption (standby)	40 W
Power consumption (PowerSave)	10 W
Power consumption (average operating)	280 W
Package depth	530 mm
Package width	561 mm
Package height	505 mm
Package weight	18300 g
Storage temperature (T-T)	5 - 32 °C
Operating temperature (T-T)	0 - 3100 °C
Operating relative humidity (H-H)	15 - 85 %
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	379 mm
Width	410 mm
Height	338 mm
Weight	15500 g
