Setting Up Your Printer 51
5 Ensure that Please Enter Date appears. Specify the current date, and then press the (set) button.
6 Ensure that Please Enter Time appears. Specify the current time, and then press the (set) button.
7 Press the (set) button for Fax Setup.
If you want to skip the Fax Setup, press the
(Start) button and then restart the printer.
8 Ensure that Please Enter Fax Number appears. Enter your fax number, and then press the (set)
button.
9 Ensure that Enter Fax Header Name appears. Enter a name, and then press the (set) button.
10 Press the (set) button, and then restart the printer.
Printer Setup Using the Software and Documentation Disc
1 Insert the Software and Documentation disc into your computer to start Dell Printer Easy Install .
2 Double-click the Dell C1765 Installer icon, and follow the on-screen instructions to connect the computer and
the printer.
NOTE: If the Software and Documentation disc does not automatically launch, try the following steps.
For Windows
®
XP, Windows Vista
®
, Windows 7, Windows Server
®
2003, Windows Server 2008, and Windows Server
2008 R2:
1 Click Start → All Programs (for Windows Vista and Windows 7) → Accessories (for Windows Vista and
Windows 7)
→ Run .
2 Ty p e D:\setup.exe (where D is the drive letter of the optical drive), and then click OK .
For Windows 8, Windows 8.1, Windows Server 2012 and Windows Server 2012 R2:
1 Point to the bottom right corner of the screen, and then click Search → Ty p e Run in the search box, click Apps ,
and then click
Run .
2 Ty p e D:\setup.exe (where D is the drive letter of the optical drive), and then click OK .
Pacific Ocean (UTC -11:00) Midway Island, Niue, Samoa
(UTC -10:00) Cook Islands, Hawaii, Tahiti
(UTC -09:30) Marquesas Islands
(UTC -09:00) Gambier Islands
(UTC -08:00) Pitcairn Islands
(UTC -06:00) Easter Island
(UTC -06:00) Galapagos Islands
(UTC +09:00) Palau
(UTC +10:00) Guam, Port Moresby, Saipan
(UTC +11:00) Efate, Guadalcanal, Kosrae
(UTC +11:30) Norfolk Island
(UTC +12:00) Auckland
(UTC +12:00) Fiji, Marshall Islands
(UTC +12:45) Chatham
(UTC +13:00) Tongatapu
(UTC +14:00) Kiritimati
Geographic Region Time Zone

Dell C1765NFW Specifications

General

Duplex printing	No
Print technology	LED
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	16 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	15 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Fax polling	Yes
Flash memory	16 MB
Scan file formats	JPG, PDF, TIFF
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Print, Scan
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Connectivity technology	Wired & Wireless
Color all-in-one functions	copy, print
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	30000 pages per month
Number of print cartridges	4
Page description languages	GDI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2
Time to first copy (black, normal)	24 s
Time to first copy (color, normal)	40 s
Copy speed (black, normal quality, A4)	15 cpm
Copy speed (color, normal quality, A4)	12 cpm
Scan to	E-mail, FTP, USB
Scanner type	Flatbed & ADF scanner
Input color depth	24 bit
Maximum scan area	A4 / Letter (216 x 297) mm
Image formats supported	JPG, TIF
Maximum scan resolution	4800 x 4800 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 1200 DPI
Faxing	Mono faxing
Fax memory	2 MB
Modem speed	33.6 Kbit/s
Paper input type	Paper tray
Total input capacity	150 sheets
Total output capacity	100 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	15 sheets
Envelopes sizes	7 3/4, C5, DL
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Coated paper, Envelopes, Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Hagaki card, Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Product color	Black
Market positioning	Business
Display number of lines	4 lines
Display number of characters	20
Standard interfaces	USB 2.0
Wi-Fi standards	802.11b, 802.11g
Security algorithms	128-bit WEP, 64-bit WEP, WPA-AES, WPA-TKIP, WPS
Supported network protocols (IPv4)	TCP/IP, HTTP, Port 9100, LPD/LPR, BOOTP, DHCP, RARP, Auto IP, DNS, mDNS
Internal memory	128 MB
Processor frequency	295 MHz
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	2 W
Power consumption (standby)	40 W
Power consumption (PowerSave)	10 W
Power consumption (average operating)	280 W
Package depth	530 mm
Package width	561 mm
Package height	505 mm
Package weight	18300 g
Storage temperature (T-T)	5 - 32 °C
Operating temperature (T-T)	0 - 3100 °C
Operating relative humidity (H-H)	15 - 85 %
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	379 mm
Width	410 mm
Height	338 mm
Weight	15500 g
