Restart printer to apply new settings Click this button to restart the printer and apply the changes.
Network Settings
NOTE: Network Settings is not available when the printer is connected using a USB cable.
Purpose:
To configure the setup of the printer using your web browser.
Va lu e s:
Print Server
Settings
*1
Display Click to display the Print Server Setup page on the Dell Printer Configuration
Web Tool.
Display of Dell On Displays the server settings for the Dell Printer Configuration Web Tool.
Configuration Web
Tool
Off Does not display the server settings for the Dell Printer Configuration Web Tool.
Apply New Settings After you change the settings, click this button to apply the changes.
Restart printer to apply new settings Click this button to restart the printer and apply the changes.
*1
This item is available only when Display of Dell Configuration Web Tool is set to On.
Diagnosis
The Diagnosis tab includes the Chart Print and Environment Sensor Info pages.
Chart Print
Purpose:
To print various charts that can be used for diagnosis of the printer. The chart is printed to A4 or letter size paper.
Va lu e s:
Pitch Configuration Chart Prints full halftone pages for yellow, magenta, cyan, and black. Also prints pages to
check the pitch. A total of five pages are output.
Ghost Configuration Chart Prints a chart to check for ghost printing. One page is printed.
4 Colors Configuration Chart Bands of yellow, magenta, cyan, and black are printed with varying density. One
page is printed.
Banding Detection Chart Prints charts to check which color the banding occurred and the distance between
each band.
MQ Chart Prints charts to check for the banding in A4 or Letter.
Alignment Chart Prints a chart to check for proper alignment of the print image on the paper. One
page is printed.
Environment Sensor Info
Purpose:
To print the internal environment sensor information of the printer to Result.
Va lu e s:
Get Environment Sensor Click this button to confirm the internal environment sensor information of the printer such as
Info temperature and humidity.
Understanding the Tool Box Menus
159
