Dell C2660dn User Manual

For Windows 8 and Windows Server 2012
Point to the top or bottom right corner of the screen, and then click
Search → Ty pe Run in the search box, click Apps , and
then click
Run → Ty p e D:\setup_assist.exe (where D is the drive letter of the optical drive), and then click
OK .
Direct Connection Setup
For installing PCL and PS printer driver
1 In the Dell Printer Setup window, click Install Printer Driver and Software to launch the installation software.
2 Select Personal Installation , and then click Next .
3 Follow the on-screen instructions to connect the computer and the printer with a USB cable, and then turn the
printer on.
The Plug and Play installation starts and the installation software proceeds to the next page automatically.
NOTE: If the installation software does not automatically proceed to the next page, click Install.
4 Select either Typical Installation (recommended) or Custom Installation from the installation wizard, and then
click
Install . If you select Custom Installation , you can select the specific software you want to install.
5 If you agree to the terms of the Environmental Information Notice , select Use duplex printing check box, and
click
Install to continue the installation.
6 Click Finish to exit the wizard when the Ready to Print! screen appears.
If you want to verify installation, click
Print Test Page before clicking Finish .
Personal Installation
A personal printer is a printer connected to your computer or a print server using a USB. If your printer is connected
to a network and not your computer, see "Network Connection Setup."
For installing XML Paper Specification (XPS) printer driver
NOTE: XPS driver is supported on the following operating systems: Windows Vista, Windows Vista 64-bit Edition, Windows
Server 2008, Windows Server 2008 64-bit Edition, Windows Server 2008 R2, Windows 7, Windows 7 64-bit Edition, Windows 8,
Windows 8 64-bit Edition, and Windows Server 2012.
NOTE: If you are using Windows Vista or Windows Server 2008, you need to install Service Pack 2 or later, and then the
Windows Platform Update (KB971644). The update (KB971644) is available for download from Windows Update.
Windows Vista or Windows Vista 64-bit Edition
1
Extract the following zip file to your desired location.
D:\Drivers\XPS\Win_7Vista\XPS-V3_C2660.zip (where D is the drive letter of the optical drive)
2 Click Start → Control Panel → Hardware and Sound → Printers .
3 Click Add a printer .
4 Click Add a local printer .
5 Select the port connected to this product, and then click Next .
6 Click Have Disk to display the Install From Disk dialog box.
7 Click Browse , and then select the extracted folder in step 1.
8 Click OK .
9 Select your printer name and click Next .
Installing Printer Drivers on Windows
®
Computers 66

Dell C2660dn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Print speed (black, normal quality, A4/US Letter)	27 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	50000 pages per month
Recommended duty cycle	750 - 3500 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 6, PostScript 3
Paper input type	Paper tray
Total input capacity	400 sheets
Total output capacity	250 sheets
Maximum input capacity	950 sheets
Envelopes sizes	10, C5, DL, Monarch
Maximum print size	216 x 356 mm
Paper tray media types	Coated paper, Envelopes, Heavy paper, Labels, Plain paper, Recycled paper, Thick paper
Paper tray media weight	60 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	SSL/TLS
Mobile printing technologies	Not supported
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	5
Noise level (idle)	25.5 dB
Maximum internal memory	- MB
Sound pressure level (printing)	53 dB
Display	LCD
Certification	GS, RoHS, WEEE, ErP Lot 6
Product color	Black
Display number of lines	4 lines
AC input voltage	230 V
Power consumption (printing)	- W
Sustainability certificates	Blue Angel, ENERGY STAR
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supported	RedHat EL Linux 5.0, SuSE Linux 10, SuSE Linux 11
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Package depth	686 mm
Package width	570 mm
Package height	526 mm
Package weight	30500 g
Cables included	AC

Weight and Dimensions

Depth	485 mm
Width	439 mm
Height	379 mm
