26
Removing Options
If the printer location needs to change or the printer and print media handling options need to be shipped to a new
location, all print media handling options must be removed from the printer. For shipping, pack the printer and print
media handling options securely to avoid damage.
Removing the Optional 550-Sheet Feeder
WARNING: When you remove the optional 550-sheet feeder (Tray2), be sure to turn off the printer, unplug the power cable, and
disconnect all cables from the back of the printer before starting these tasks.
1
Ensure that the printer is turned off, and then disconnect all cables from the back of the printer.
2
Pull the tray1 out of the printer about 200 mm.
3
Hold tray1 with both hands, and remove it from the printer.
Removing Options 303
