10 Print the printer settings report to confirm that the optional 550-sheet feeder is installed correctly.
For details about how to print a printer settings report, see "Report / List."
11 Confirm Tray2 (550 Sheet Feeder) is listed in the printer settings report under Printer Options .
If the feeder is not listed, turn off the printer, unplug the power cable, and re-install the optional 550-sheet feeder.
12 After loading paper in the optional 550-sheet feeder, specify the paper type from the operator panel.
a Press the (Menu) button.
b Press the button until Tray Settings is highlighted, and then press the (Set) button.
c Press the button until Tray 2 is highlighted, and then press the (Set) button.
d Press the button until Paper Type is highlighted, and then press the (Set) button.
e Press the button until the paper type for the optional 550-sheet feeder is displayed, and then press the
(Set) button.
f Confirm that the selected paper type is highlighted, and then press the (Menu) button.
13 If you installed the optional 550-sheet feeder after installing the printer driver, update your driver by following the
instructions for each operating system. If the printer is on a network, update the driver for each client.
Updating Your Driver to Detect 550-Sheet Feeder
When Using PCL Driver
Windows 8/
Windows 8 x64/
Windows Server 2012
Windows 7/
7 x64/
Server 2008 R2 x64
1 Under Desktop mode, right-click the bottom left corner of the screen, and then click
Control Panel → Hardware and Sound ( Hardware for Windows Server 2012) → Devices
and Printers .
2 Right-click the printer icon of the Dell C2660dn Color Laser Printer, and then select Printer
properties .
3 Click the Configuration tab, and then select Bi-Directional Setup .
4 Select Get Information from Printer and then click OK .
5 Click Apply , and then click OK .
6 Close the Devices and Printers dialog box.
1 Click Start → Devices and Printers .
2 Right-click the printer icon of the Dell C2660dn Color Laser Printer, and then select Printer
properties
.
3 Click the Configuration tab, and then select Bi-Directional Setup .
4 Select Get Information from Printer and then click OK .
5 Click Apply , and then click OK .
6 Close the Devices and Printers dialog box.
Windows Vista/Vista x64 1 Click Start → Control Panel → Hardware and Sound → Printers .
2 Right-click the printer icon of the Dell C2660dn Color Laser Printer, and then select
Properties .
3 Click the Configuration tab, and then select Bi-Directional Setup .
4 Select Get Information from Printer and then click OK .
5 Click Apply , and then click OK .
6 Close the Printers dialog box.
Installing Optional Accessories 39

Dell C2660dn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Print speed (black, normal quality, A4/US Letter)	27 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	50000 pages per month
Recommended duty cycle	750 - 3500 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 6, PostScript 3
Paper input type	Paper tray
Total input capacity	400 sheets
Total output capacity	250 sheets
Maximum input capacity	950 sheets
Envelopes sizes	10, C5, DL, Monarch
Maximum print size	216 x 356 mm
Paper tray media types	Coated paper, Envelopes, Heavy paper, Labels, Plain paper, Recycled paper, Thick paper
Paper tray media weight	60 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	SSL/TLS
Mobile printing technologies	Not supported
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	5
Noise level (idle)	25.5 dB
Maximum internal memory	- MB
Sound pressure level (printing)	53 dB
Display	LCD
Certification	GS, RoHS, WEEE, ErP Lot 6
Product color	Black
Display number of lines	4 lines
AC input voltage	230 V
Power consumption (printing)	- W
Sustainability certificates	Blue Angel, ENERGY STAR
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supported	RedHat EL Linux 5.0, SuSE Linux 10, SuSE Linux 11
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Package depth	686 mm
Package width	570 mm
Package height	526 mm
Package weight	30500 g
Cables included	AC

Weight and Dimensions

Depth	485 mm
Width	439 mm
Height	379 mm
