Dell Inspiron 14 5420 User Manual

Steps
1. Peel off the tape that secures the display-cable connector latch to the system board.
2. Open the latch and disconnect the display cable from the system board.
3. Open the display assembly to a 90-degree angle and place the computer on the edge of a table.
4. Remove the five screws (M2.5x5) that secure the display-assembly to the palm-rest and keyboard assembly.
5. Gently lift the palm-rest and keyboard assembly off the display assembly.
Installing the display assembly
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following image(s) indicate the location of the display assembly and provides a visual representation of the installation
procedure.
Removing and installing components
29

Dell Inspiron 14 5420 Specifications

General

Graphics	Intel Iris Xe Graphics
Operating System	Windows 11 Home
Battery	4-Cell Battery, 54WHr (Integrated)
Processor	12th Gen Intel Core i5-1235U
Display	14-inch FHD (1920 x 1080)
RAM	8GB DDR4
Storage	256GB/512GB/1TB SSD
Ports	2 x USB 3.2 Gen 1
Wireless	Bluetooth
