Dell Inspiron 14 5420 User Manual

System-diagnostic lights
The power and battery status light indicates the power and battery status of the computer. These are the power states:
Solid white: Power adapter is connected, and the battery has more than 5% charge.
Amber: Computer is running on battery, and the battery has less than 5% charge.
Off:
● Power adapter is connected, and the battery is fully charged.
● Computer is running on battery, and the battery has more than 5% charge.
●
Computer is in sleep state, hibernation, or turned off.
The power and battery-status light may also blink amber or white according to predefined "beep codes" indicating various
failures.
For example, the power and battery-status light blinks amber two times followed by a pause, and then blinks white three times
followed by a pause. This 2,3 pattern continues until the computer is turned off, indicating no memory or RAM is detected.
The following table shows different power and battery-status light patterns and associated problems.
NOTE: The following diagnostic light codes and recommended solutions are intended for Dell service technicians to
troubleshoot problems. You should only perform troubleshooting and repairs as authorized or directed by the Dell technical
support team. Damage due to servicing that is not authorized by Dell is not covered by your warranty.
Table 15. Diagnostic-light codes
Diagnostic light codes
(Amber, white)
Problem description
1,1 TPM detection failure
1,2 Unrecoverable SPI flash failure
1,3 Short in hinge cable tripped OCP1
1,4 Short in hinge cable tripped OCP2
1,5 EC unable to program i-Fuse
1,6 EC internal Failure
2,1 Processor failure
2,2 System board: BIOS or ROM (Read-Only
Memory) failure
2,3 No memory or RAM (Random-Access Memory)
detected
2,4 Memory or RAM (Random-Access Memory)
failure
2,5 Invalid memory installed
2,6 System-board or chipset error
2,7 Display failure - SBIOS message
2,8 Display failure - EC detection of power rail
failure
3,1 CMOS battery failure
3,2 PCI, video card/chip failure
3,3 BIOS recovery image not found
3,4 Recovery image found but invalid
3,5 Power-rail failure
3,6 System BIOS Flash incomplete
3,7 Management Engine (ME) error
Troubleshooting 65

Dell Inspiron 14 5420 Specifications

General

Graphics	Intel Iris Xe Graphics
Operating System	Windows 11 Home
Battery	4-Cell Battery, 54WHr (Integrated)
Processor	12th Gen Intel Core i5-1235U
Display	14-inch FHD (1920 x 1080)
RAM	8GB DDR4
Storage	256GB/512GB/1TB SSD
Ports	2 x USB 3.2 Gen 1
Wireless	Bluetooth
