Audio Connector Cover
Dell™Inspiron™1545ServiceManual
Removing the Audio Connector Cover
Replacing the Audio Connector Cover
Removing the Audio Connector Cover
1. Follow the instructions in Before You Begin.
2. Remove the system board (see Removing the System Board).
3. Lift the audio connector cover and remove it from the computer.
Replacing the Audio Connector Cover
1. Place the audio connector cover in the computer base.
2. Replace the system board (see Replacing the System Board).
Back to Contents Page
CAUTION: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such
as a connector on the back of the computer).
NOTICE: To help prevent damage to the system board, remove the main battery (see Before Working Inside Your Computer) before working inside the
computer.
NOTICE: Onlyacertifiedservicetechnicianshouldperformrepairsonyourcomputer.DamageduetoservicingthatisnotauthorizedbyDell™isnot
covered by your warranty.
