126 Removing and Installing Parts
Installing Memory
CAUTION: Before you begin any of the procedures in this section, follow the
safety instructions in the Product Information Guide.
CAUTION: Before installing memory, you must remove the PCI Express x16 card.
See "Cards" on page 129.
NOTICE: To prevent static damage to components inside your computer, discharge
static electricity from your body before you touch any of your computer’s electronic
components. You can do so by touching an unpainted metal surface on the
computer chassis.
1
Follow the procedures in "Before You Begin" on page 105.
2
Press the securing clip at each end of the memory module connector.
Inspiron 530/530a/530c
1 memory connector closest
from processor (DIMM_1)
2 securing clips (2) 3 connector
2
3
book.book Page 126 Monday, October 6, 2008 11:28 AM
