Removing and Installing Parts 151
Media Card Reader
CAUTION: Before you begin any of the procedures in this section, follow the
safety instructions in the Product Information Guide.
CAUTION: To guard against electrical shock, always unplug your computer from
the electrical outlet before removing the cover.
Removing a Media Card Reader
1
Follow the procedures in "Before You Begin" on page 105.
2
Remove the computer cover (see "Removing the Computer Cover" on
page 107).
3
Remove the bezel (see "Removing the Bezel" on page 136).
1 Media Card Reader 2 data cable 3 power cable
4 system board connector 5 custom screws (2)
*1
*
Not present on all computers.
2
4
3
5
book.book Page 151 Monday, October 6, 2008 11:28 AM
