136 Removing and Installing Parts
Bezel
CAUTION: Before you begin any of the procedures in this section, follow the
safety instructions in the Product Information Guide.
CAUTION: To guard against electrical shock, always unplug your computer from
the electrical outlet before removing the cover.
Removing the Bezel
1
Follow the procedures in "Before You Begin" on page 105.
2
Remove the computer cover (see "Removing the Computer Cover" on
page 107).
3
Grasp and lift the bezel grips one at a time to release it from the front panel.
1 bezel grip (3) 2 bezel 3 bezel clamp (3)
4 clamp insert (3) 5 back of computer
3
4
5
1
2
book.book Page 136 Monday, October 6, 2008 11:28 AM
