Removing and Installing Parts 173
2
Remove the computer cover (see "Removing the Computer Cover" on
page 107).
3
Remove the four screws securing the chassis fan.
4
Slide the chassis fan towards the front of the computer and lift it up.
Replacing the Chassis Fan
1
Follow the procedures in "Before You Begin" on page 105.
2
Remove the computer cover (see "Removing the Computer Cover" on
page 107).
3
Slide the chassis fan in place towards the back of the computer.
4
Tighten the four screws to secure the chassis fan.
1 screws (4) 2 chassis fan
2
1
book.book Page 173 Monday, October 6, 2008 11:28 AM
