Removing the LED Board
1. Follow the instructions in "Preparing to Work Inside the Computer."
2. Remove the
hinge cover.
3. Remove the two M2 x 4-mm screws.
4. Lift the LED board away from its connector.
Replacing the LED Board
1. Align the two screw holes with the two mounting holes on the bottom case, and
press the board into its connector.
2. Replace the two M2 x 4-mm screws.
Back to Contents Page
