126 Adding and Replacing Parts
www.dell.com | support.dell.com
Keyboard
CAUTION: Before performing the following procedures, follow the safety instructions in your Product
Information Guide .
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by
periodically touching an unpainted metal surface (such as the back panel) on the computer.
1 Follow the instructions in "Before You Begin" on page 123.
2 Remove the hinge cover (see "Hinge Cover" on page 125).
NOTICE: The keycaps on the keyboard are fragile, easily dislodged, and time-consuming to replace. Be
careful when removing and handling the keyboard.
3 Remove the three screws across the top of the keyboard.
NOTE: Lift the keyboard carefully in step 4 to ensure that you do not pull on the keyboard cable.
4 Rotate the keyboard up 90-degrees and lay it on the palm rest to gain access to the keyboard
connector.
5 If the keyboard cable is held in place by a keyboard lock arm next to the keyboard connector,
carefully pivot the lock arm upward to uncover the cable.
1 screws (3) 2 keyboard tabs (5) 3 palm rest
4 pull-tab 5 keyboard-cable locking arm 6 keyboard cable connector
2
1
3
4
5
6
