164 Mini Tower Computer Parts
7
Replace the card retention bracket, ensuring that:
• The guide clamp is aligned with the guide notch.
• The tops of all cards and filler brackets are flush with the alignment
bar.
• The notch in the top of the card or filler bracket fits around the
alignment guide.
8
Fix the card retention bracket by replacing and tightening the screw.
9
Replace the computer cover.
NOTICE: To connect a network cable, first plug the cable into the network device
and then plug it into the computer.
10
Reconnect the computer and devices to electrical outlets, and then turn
them on.
11
Remove the card’s driver from the operating system.
12
If you removed a sound card:
a
Enter system setup (see "Entering System Setup" on page 79), go to
Onboard Devices
and select
Integrated Audio
, and then change the
setting to
On
.
b
Connect external audio devices to the audio connectors on the back
panel of the computer (see "Back Panel Connectors" on page 24).
13
If you removed an add-in network connector:
a
Enter system setup (see "Entering System Setup" on page 79), go to
Onboard Devices
and select
Integrated NIC
, and then change the
setting to
On
.
b
Connect the network cable to the integrated connector on the back
panel of the computer (see "Back Panel Connectors" on page 24).
Bezel
CAUTION: Before you begin any of the procedures in this section, follow the
safety instructions in the Product Information Guide.
CAUTION: To guard against electrical shock, laceration by moving fan blades, or
other unexpected injuries, always unplug your computer from the electrical outlet
before removing the cover.
