Dell OptiPlex 760 User Manual


Ultra Small Form Factor System Board Screws
Replacing the System Board

1. Gently align the board into the chassis and slide it toward the back of the computer.

2. Replace the screws on the system board.

3. Replace any components and cables that you removed from the system board.

4. Reconnect all cables to their connectors at the back of the computer.

5. Replace the computer cover (see Replacing the Computer Cover).
1
screws (9)
1
screws (10)
NOTE: The system board is shipped in manufacturing mode. The user or service provider must select the manageability option upon first boot. See
Manageability on how to select the manageability mode.

Dell OptiPlex 760 Specifications

General

Optical Drive	DVD-ROM, DVD+/-RW
Audio	Integrated High Definition Audio
Processor	Intel Core 2 Duo
Chipset	Intel Q43 Express
Memory	Up to 8GB DDR2
Storage	Up to 1TB SATA HDD
Graphics	Integrated Intel Graphics Media Accelerator 4500
Network	Integrated Gigabit Ethernet
Ports	USB 2.0, VGA, DisplayPort
Operating System	Windows Vista, Windows XP
Form Factor	Mini Tower, Desktop, Small Form Factor, Ultra Small Form Factor
Power Supply	235W (Small Form Factor)
