Figure 52. Display assembly with WWAN-antenna cables
Installing the display assembly
CAUTION: The information in this installation section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
NOTE:
Ensure that the hinges are opened to the maximum before replacing the display assembly on the palm-rest and
keyboard assembly.
The following images indicate the location of the display assembly and provide a visual representation of the installation
procedure.
Removing and installing Field Replaceable Units (FRUs)
81
