Dell P80F User Manual

Next steps
1. Replace the coin cell battery.
2. Replace the system board.
NOTE: System board can be replaced with heatsink attached.
3. Replace the WLAN card.
4. Replace the DC-in.
5. Replace the system fan.
6. Replace the memory module.
7. Replace the speaker.
8. Replace the battery.
9. Replace the base cover.
10. Replace the microSD card.
11. Follow the procedure in after working inside your computer.
Keyboard bracket
Removing the keyboard bracket
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the microSD card.
3. Remove the base cover.
4. Remove the battery.
5. Remove the speaker.
Disassembly and reassembly
79
