Installing the display assembly
About this task
NOTE: Ensure that the hinges are opened to the maximum before replacing the display assembly on the palmrest.
Steps
1. Align and place the system chassis under the hinges of the display assembly [1].
2. Replace the six (M2.5x4) screws that secure the display assembly to the system chassis [2].
86
Disassembly and reassembly
