Replacing the power-adapter port
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1 Insert the power-adapter port into the slot on the palm-rest assembly.
2 Replace the screw (M2x3) that secures the power adapter port to the palm-rest assembly.
3 Connect the power-adapter port cable to the system board.
Post-requisites
Replace the base cover.
16
26 Replacing the power-adapter port

Dell P83G Specifications

General

Model	Dell P83G
Category	Laptop
Graphics	Intel UHD Graphics 620
Wireless	802.11ac Wi-Fi, Bluetooth 4.2
RAM	8GB DDR4
Storage	256GB SSD
Operating System	Windows 10 Pro
Ports	HDMI, SD card reader, headphone/microphone combo jack
