Next steps
1. Replace the display panel.
2. Replace the display bezel.
3. Replace the display assembly.
4. Replace the WLAN.
5. Replace the battery.
6. Replace the base cover.
7. Replace the SD memory card.
8. Follow the procedure in after working inside your computer.
Palm-rest and keyboard assembly
Removing the palmrest and keyboard assembly
Prerequisites
1. Follow the procedure in before working inside your computer
2. Remove the
SD memory card
3. Remove the base cover
4. Remove the
battery
5. Remove the WLAN
6. Remove the
Memory
7. Remove the SSD
8. Remove the
hard drive assembly
9. Remove the IO board
Removing and installing components 107
