Next steps
1. Replace the battery cable.
2. Replace the base cover
3. Replace the SD memory card
4. Follow the procedure in after working inside your computer
Speakers
Removing the speakers
Prerequisites
1. Follow the procedure in before working inside your computer
2. Remove the SD memory card
3. Remove the
base cover
4. Disconnect the battery cable.
Steps
1. Disconnect the speaker cable from the system board [1].
2. Peel the tape that secures the speaker cables to the palm rest and keyboard assembly [2].
3. Unroute and remove the speaker cable from the routing guides on palm rest and keyboard assembly
[3]
.
Removing and installing components 55
