Dell PE R720XD User Manual

Item Button Description
During message scrolling:
• Press once to increase
scrolling speed
• Press again to stop
• Press again to return to
default scrolling speed
• Press again to repeat the
cycle
Home Screen
The Home screen displays user-configurable information about the system. This screen is displayed during normal
system operation when there are no status messages or errors. When the system is in standby mode, the LCD backlight
turns off after five minutes of inactivity if there are no error messages. Press one of the three navigation buttons (Select,
Left, or Right) to view the Home screen.
To navigate to the Home screen from another menu, continue to select the up arrow until the Home icon is
displayed, and then select the Home icon.
From the Home screen, press the Select button to enter the main menu.
Setup Menu
NOTE: When you select an option in the Setup menu, you must confirm the option before proceeding to the next
action.
Option Description
iDRAC Select DHCP or Static IP to configure the network mode. If Static IP is selected, the available fields are IP,
Subnet (Sub), and Gateway (Gtw). Select Setup DNS to enable DNS and to view domain addresses. Two
separate DNS entries are available.
Set error Select SEL to display LCD error messages in a format that matches the IPMI description in the SEL. This is
useful when trying to match an LCD message with an SEL entry.
Select Simple to display LCD error messages in a simplified user-friendly description. See System Error
Messages for a list of messages in this format.
Set home Select the default information to be displayed on the LCD Home screen. See View Menu to see the options
and option items that can be set as the default on the Home screen.
View Menu
NOTE: When you select an option in the View menu, you must confirm the option before proceeding to the next
action.
Option
Description
iDRAC IP Displays the IPv4 or IPv6 addresses for the iDRAC7. Addresses include DNS (Primary and Secondary),
Gateway, IP, and Subnet (IPv6 does not have Subnet).
13

Dell PE R720XD Specifications

General

Product Type	Server
Maximum Processors	2
Chipset	Intel C600 series
Maximum Memory	768GB
Memory Slots	24
Processor	Intel Xeon E5-2600 series
Memory Type	DDR3
Drive Bays	12 x 3.5"
RAID Support	PERC H310
Power Supply	750W or 1100W
Network Controller	Broadcom 5720
Expansion Slots	7
Operating System	Windows Server, Linux, VMware
