Option Description
MAC Displays the MAC addresses for iDRAC, iSCSI, or Network devices.
Name Displays the name of the Host, Model, or User String for the system
Number Displays the Asset tag or the Service tag for the system.
Power Displays the power output of the system in BTU/hr or Watts. The display format can be configured in the
Set home submenu of the Setup menu.
Temperature Displays the temperature of the system in Celsius or Fahrenheit. The display format can be configured in
the Set home submenu of the Setup menu.
Diagnostic Indicators
NOTE: The diagnostic indicators are present only on PowerEdge R720xd.
The diagnostic indicators on the system front panel display error status during system startup.
NOTE: No diagnostic indicators are lit when the system is switched off. To start the system, plug it into a working
power source and press the power button.
The following section describes system conditions and possible corrective actions associated with these indicators:
Health indicator
Condition Corrective Action
If the system is on, and in good health, the indicator
lights solid blue.
None required.
The indicator blinks amber if the system is on or in
standby, and any error exists (for example, a failed
fan or hard drive)
See the System Event Log or system messages for the
specific issue.
Invalid memory configurations can cause the system
to halt at startup without any video output. See
Getting Help.
Hard-drive indicator
Condition Corrective Action
The indicator blinks amber if
a hard drive experiences an
error.
See the System Event Log to determine the hard drive that has an error. Run
the appropriate Online Diagnostics test. Restart system and run embedded
diagnostics (ePSA). If the hard drives are configured in a RAID array, restart
the system and enter the host adapter configuration utility program.
Electrical indicator
Condition Corrective Action
The indicator blinks amber if the system
experiences an electrical error (for
See the System Event Log or system messages for the specific
issue. If it is due to a problem with the power supply, check the
14
