Figure 19. Removing and Installing a 2.5 Inch Hard-Drive Blank

1. hard-drive blank

2. release button

Installing A 2.5 Inch Hard-Drive Blank

1. If installed, remove the front bezel.

2. Insert the hard-drive blank into the hard-drive slot until the release button clicks into place.

3. If applicable, install the front bezel.

Removing A 2.5 Inch Hard-Drive Blank (Back)

NOTE: This procedure applies only to PowerEdge R720xd.

CAUTION: To maintain proper system cooling, all empty hard-drive slots must have drive blanks installed.

Pull the hard-drive blank out until it is free of the hard-drive slot.

Figure 20. Removing and Installing a 2.5 Inch Hard-Drive Blank (Back)

1. hard-drive blank (back)
