Dell PowerEdge FX2 Deployment Guide

100 PowerEdge FX2 – FN I/O Module – VLT Deployment Guide | Version 2.2
E FN IOM initial out-of-box configuration and default
settings
This section applies to the Dell PowerEdge FN I/O Module (FN IOM) in Standalone mode. Modules in
this section include the FN410S, FN410T, and FN2210S (applicable to ports in Ethernet mode only).
This section provides configuration examples for common upstream switches to establish a functional
uplink and bring up network ports on PowerEdge FC-Series servers (FC830, FC630, FC430, FC620
and FC420) in three easy steps:
1. Ensure the FN IOM is in Standalone Mode
2. Create an LACP LAG on the upstream top-of-rack (ToR) switch
3. Verify the connection
Note: This section covers basic configuration in a factory default standalone mode and is not
required for VLT configuration.
By default, the FN IOM is shipped from the factory in Standalone Mode, which consists of the following
default settings:
Setting
Default Value
Chassis Management Controller
Configuration
Yes
Stacking and VLT
Disabled
Data Center Bridging Exchange Protocol
(DCBx)
Enabled
FIP Snooping Bridge (FSB)
Enabled on FN 410S and FN 410T
Disabled on FN 2210S
NPIV Proxy Gateway Mode (NPG)
Enabled in FN 2210S
Disabled on FN 410S and FN 410T
iSCSI Optimization
Enabled
Broadcast Storm Control
Enabled
Internet Group Management Protocol
(IGMP) Flood Restrict
Enabled
Network Time Protocol (NTP)
Enabled
Enable and Disable ports
All ports enabled by default.
Disable ports via Command Line
Interface
Uplink Failure Detection (UFD)
Enabled
TACACS+/RADIUS (AAA Auth/Acct; Auth
coming up)
Disabled
DHCP
Enabled in client only mode
Internet Group Management Protocol
(IGMP) v2 & v3
Enabled

Dell PowerEdge FX2 Specifications

General

Product color	Black, Silver
Rack capacity	2U
LED indicators	Yes
Number of fans	8 fan(s)
Heat dissipation	475 BTU/h
Dell E-Value Code	PEFX2Chassis
Input current	25 A
AC input voltage	100 - 240 V
Power requirements	1600W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	851.6 mm
Width	433.5 mm
Height	86.8 mm
