Dell PowerEdge FX2 Deployment Guide

53 PowerEdge FX2 – FN I/O Module – VLT Deployment Guide | Version 2.2
8.1.1 Configuring the FN IOM for programmable MUX mode
In this section, the switch is set to Programmable MUX (PMUX) mode.
In Figure 38, configuration mode is used to set the switch to PMUX IOM mode, then the configuration
is saved and the switch is reloaded. Once the reload is complete, the IOM mode is verified using the
show system stack-unit iom- mode command. Then, the management IP address is assigned
to allow VLT heartbeats as well as SSH/telnet access.
Note: Only the VLT-related portions of the configurations are shown.
FN410S-A1
FN410S-A2
Configure the IOM for
Programmable MUX mode
Configure the IOM for
Programmable MUX mode
configure
stack-unit 0 iom-mode
programmable-mux
end
configure
stack-unit 0 iom-mode
programmable-mux
end
Verify that the system is set to move
to Programmable-MUX mode for the
next-boot and reload
Verify that the system is set
to move to Programmable-
MUX mode for the next-boot
and reload
show system stack-unit 0
iom-mode
reload
show system stack-unit
0 iom-mode
reload
Confirm the iom-mode
Configure the Management IP
address
Confirm the iom-mode
Configure the Management
IP address
show system stack-unit 0
iom-mode
configure
interface ma0/0
ip address
172.25.189.27/16
show system stack-unit
0 iom-mode
configure
interface ma0/0
ip address
172.25.189.28/16
Configuring the FN IOM for PMUX mode

Dell PowerEdge FX2 Specifications

General

Product color	Black, Silver
Rack capacity	2U
LED indicators	Yes
Number of fans	8 fan(s)
Heat dissipation	475 BTU/h
Dell E-Value Code	PEFX2Chassis
Input current	25 A
AC input voltage	100 - 240 V
Power requirements	1600W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	851.6 mm
Width	433.5 mm
Height	86.8 mm
