Dell PowerEdge FX2 Deployment Guide

52 PowerEdge FX2 – FN I/O Module – VLT Deployment Guide | Version 2.2
8.1 Environment Three: FN IOM configuration
The configuration steps outlined below are repeated on both IOMs. When validating the configurations
in this guide the following management IP addresses (Table 9) were used.
Management IP address
Hostname
IP Address
Subnet
FN410S-A1
172.25.189.27
255.255.0.0
FN410S-A2
172.25.189.28
255.255.0.0
Note: If the IOMs have been previously configured, existing configuration settings will be retained
when changing IOM modes. Because of this, it is recommended that the IOMs be returned to factory
defaults before configuring. See the Reset FN IOM to Default Factory Configuration section for
instructions on setting an IOM back to factory defaults.

Dell PowerEdge FX2 Specifications

General

Product color	Black, Silver
Rack capacity	2U
LED indicators	Yes
Number of fans	8 fan(s)
Heat dissipation	475 BTU/h
Dell E-Value Code	PEFX2Chassis
Input current	25 A
AC input voltage	100 - 240 V
Power requirements	1600W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	851.6 mm
Width	433.5 mm
Height	86.8 mm
