Dell PowerEdge R320 Planning, Installation And Service Guide

Chapter 2 - Planning
Model
number
Description
MZ-
PCSV61
Intel Xeon E5-2430V2 2.50 GHz, 15M Cache/8 GB RDIMM ( 2x4 GB)/146 GB
or 300 GB 15K RPM Serial-Attach SCSI 6 Gbps 2.5 in Hot plug Hard Drive
(QTY 4)/H710mini Controller (RAID 5 configuration)
MZ-
PCEH02
146 GB or 300 GB 2.5” 15K RPM SAS HDD to use as a Hot Spare (if the hot
spare is required, then you need to buy it as it is not supplied with the standard
configuration-obsolete)
MZ-
PCEH06
300 GB 2.5” 15K RPM SAS HDD to use as a Hot Spare (if the hot spare is
required, then you need to buy it as it is not supplied with the standard
configuration)
EP-
COA2K8
Microsoft Windows Server 2008 (32-bit) COA
EP-
COAR28
Microsoft Windows Server 2008 R2 COA
EP-
COAS16
Microsoft windows Server 2016,64Bit COA
2.2.2 Electronics configuration
The Dell R320-based server is approved for installation in the Honeywell 1000 mm deep LCN cabinet
only, using the Sliding ReadyRail II kit included in the purchase of the server.
2.2.3 Electronics module
The tables in this section provides the electronics module for the Honeywell-based Dell R320 server
platforms, which includes MLK and pre-MLK servers.
Typical operating power requirements
Description DC power AC voltage AC RMS current AC power
Electronic assembly N/A 120 (90-132) Vrms
240 (180-260) Vrms
0.91A
0.47A
88W
89W
Maximum operating power requirements
Description DC power AC voltage AC RMS current AC power
Electronic assembly N/A 120 (90-132) Vrms
240 (180-260) Vrms
1.68
0.87
163W
160W
- 12 -

Dell PowerEdge R320 Specifications

General

Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR0LS
Processor cache	10 MB
Processor cores	4
Processor model	E5-2403
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2400
Processor socket	LGA 1356 (Socket B2)
Processor codename	Sandy Bridge EN
Motherboard chipset	Intel C600
Processor frequency	1.8 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	45 x 42.5 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	24
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25 GB/s
Maximum internal memory supported by processor	375 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD capacity	1000 GB
HDD interface	Serial ATA
Optical drive type	DVD-RW
Total storage capacity	2000 GB
Maximum storage capacity	16 TB
Number of HDDs installed	2
Memory slots	6x DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	96 GB
Cabling technology	10/100/1000Base-T(X)
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express slots version	3.0
Power supply	350 W
Compatible operating systems	Microsoft Windows Server 2012 \\r Microsoft Windows Server 2012 Essentials\\r Microsoft Windows Server 2008 R2 \\r Novell SUSE Linux Enterprise Server\\r Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Chassis type	Rack (1U)
Processor ARK ID	64615
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Width	- mm
