Dell PowerEdge R320 Planning, Installation And Service Guide

1. From the front of the cabinet, open the door to access the mounting rails.
2. Fully extend the right and left Sliding Ready Rails (pre-installed in the Honeywell factory).
3. Lower the server into the J-shaped slots on each slide, starting with the slot that is closest to the
cabinet.
4. Depress the slide locks and push the server toward the cabinet until the front bezel mounting ears
makes contact with the front of the Sliding ReadyRails.
5. Engage the screw captivated in each mounting ear of the server front bezel with the threaded
inserts in the front of the Sliding ReadyRails. Hand-tighten these screws.
ATTENTION
The Sliding Ready Rails kit includes a cable management arm (installed in the
Honeywell factory) that mounts to the rear of the Sliding Ready Rails. AC power cords
and KVM cables are prerouted through the cable management arm. For additional
information, refer to the “Rack Installation Guide” shipped with the cabinet.
6. If you are using the 8-port KVM switch/control console for your human interface (pre-installed in the
Honeywell factory), connect the KVM cable mouse and keyboard connections to the USB
connectors on the rear of the server. The KVM cable may have separate USB connections for the
mouse and keyboard or they may be combined into one USB connector through a USB to PS/2
adapter (included with the KVM cable).
3.4.3 Connecting the cables
To connect the cables
1. Connect the video and network interface cables.
WARNING
AC power cords from all computing nodes mounted in a given cabinet must be distributed
across the two power entries as equally as possible. Failure to do so may result in tripping
the circuit breakers.
2. Connect the Honeywell AC power cords.
3. Perform any one of the following, as necessary.
l If you are not using Fault Tolerant Ethernet (FTE), connect the Ethernet cable to the on-board
RJ-45 connector.
l If you are using an Intel dual NIC card for FTE, connect the FTE cable to the NIC card in the
expansion slot.
l If you are using the on-board NICs for FTE, connect the FTE cable to the onboard RJ-45
connector.
4. Secure any loose cables, and verify that all cables have proper strain relief.
- 32 -
Chapter 3 - Installation

Dell PowerEdge R320 Specifications

General

Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR0LS
Processor cache	10 MB
Processor cores	4
Processor model	E5-2403
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2400
Processor socket	LGA 1356 (Socket B2)
Processor codename	Sandy Bridge EN
Motherboard chipset	Intel C600
Processor frequency	1.8 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	45 x 42.5 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	24
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25 GB/s
Maximum internal memory supported by processor	375 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD capacity	1000 GB
HDD interface	Serial ATA
Optical drive type	DVD-RW
Total storage capacity	2000 GB
Maximum storage capacity	16 TB
Number of HDDs installed	2
Memory slots	6x DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	96 GB
Cabling technology	10/100/1000Base-T(X)
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express slots version	3.0
Power supply	350 W
Compatible operating systems	Microsoft Windows Server 2012 \\r Microsoft Windows Server 2012 Essentials\\r Microsoft Windows Server 2008 R2 \\r Novell SUSE Linux Enterprise Server\\r Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Chassis type	Rack (1U)
Processor ARK ID	64615
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Width	- mm
