Dell PowerEdge R320 Planning, Installation And Service Guide

l Monitor
l Video cable
2.7.19 Hard disk drive specifications
The Honeywell-based Dell R320 has four hard disk drive bays. It uses four 146 GB or 300 GB SAS 2.5”
hard drives for RAID-5 (distributed parity). A 5th 146 GB or 300 GB 2.5” 15K RPM SAS HDD hot spare is
available and must be bought separately (P/N MZ-PCEH01). The following table provides the operating
power requirements for 146 GB or 300 GB hard drive.
Description Requirement
DC 5 volt Power (typ) 2.25 w
DC 12 volt Power (typ) 13.44 Watts +10%, -8%
Other DC POWER 16 Watts Max, 4.1 Watts idle
AC Power N/A
The following table provides the maximum weight and dimensions for 146 GB or 300 GB hard drive.
Description Requirement
Height 14.81 mm
Width 70 mm
Depth 100.5 mm
Weight 0.201 kg
2.7.20 Removable media specifications
The Honeywell-based Dell R320 server has one SATA DVD- RW drive. The SATA DVD-RW drive is
connected to the SATA connector on the motherboard. DC 5 volt power, 6.5 Watts is the operating
power requirement for DVD RW drive.
2.7.21 Storage and media devices
All mass storage devices are connected through SATA and PCIe. SATA DVDRW drive is connected
through the SATA connector on the motherboard. The RAID-5 SAS controller card is located on server
motherboard. The standard mass storage for this platform has 4 x 146 GB or 300 GB 2.5” 15K RPM SAS
hard drives, where drives 0, 1, 2 and 3 are in a RAID-5 configuration. The option of 5th 146 GB 2.5” 15K
RPM SAS HDD as a hot spare is available, you must purchase it separately (P/N MZ-PCEH02).
2.7.22 Mouse and keyboard
The USB mouse, a standard cursor control device and an USB standard PC keyboard are included with
the Dell R320 server.
2.7.23 Monitor
The Honeywell-based Dell R320 server supports industrial standard video format (typically 1024X768
at a refresh rate of 60Hz). You must use a multisync monitor along with the Dell R320 server platform
operating system. The server can be configured only with a single screen option. In this configuration,
- 25 -
Chapter 2 - Planning

Dell PowerEdge R320 Specifications

General

Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR0LS
Processor cache	10 MB
Processor cores	4
Processor model	E5-2403
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2400
Processor socket	LGA 1356 (Socket B2)
Processor codename	Sandy Bridge EN
Motherboard chipset	Intel C600
Processor frequency	1.8 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	45 x 42.5 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	24
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25 GB/s
Maximum internal memory supported by processor	375 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD capacity	1000 GB
HDD interface	Serial ATA
Optical drive type	DVD-RW
Total storage capacity	2000 GB
Maximum storage capacity	16 TB
Number of HDDs installed	2
Memory slots	6x DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	96 GB
Cabling technology	10/100/1000Base-T(X)
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express slots version	3.0
Power supply	350 W
Compatible operating systems	Microsoft Windows Server 2012 \\r Microsoft Windows Server 2012 Essentials\\r Microsoft Windows Server 2008 R2 \\r Novell SUSE Linux Enterprise Server\\r Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Chassis type	Rack (1U)
Processor ARK ID	64615
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Width	- mm
