Dell PowerEdge R320 Planning, Installation And Service Guide

Weight and dimensions
Description Height Width Depth Weight
Assembly 42.8 mm 482.44 mm 677.3 mm 19.3 KGs (42.5)
2.2.4 Standard features of Dell R320
Following are the common features of pre-MLK server:
l Intel Xeon E5-2430 2.20 GHz, 15M Cache / 4 GB RDIMM (2x2 GB) / 146 GB 15K RPM Serial-Attach
SCSI 6 Gbps 2.5in Hot plug Hard Drive (QTY 4)/H710 mini Controller (RAID 5 configuration)
l 1 serial, 1Video, 2 USB V2.0, 2 RJ45, 1 ID push button with blue/amber LED.
l 2 USB 2.0, ID push button with blue/amber LED, 1 video, 1 system power on/off button.
l Broadcom 5720 1GBE Dual Port Ethernet NIC with failover and load balancing.
l 2 PCIe slots
o
1x8 slot with x4 bandwidth, 2.0, half-height, half-length
o
1x16 slot with x16 bandwidth, 3.0, full-height, half-length
l Energy Smart – Two hot-plug high-efficient 350 W Watts Power Supply.
l Two 110 Volt / 230 Volts Power Cords
l 4 GB RAM 2x2 GB or 8 GB RAM 2x4 GB RDIMM 1333 MHz or faster
l SATA DVD-RW Drive.
l 2D Matrox®G200 graphics card
Following are the common features of MLK server:
l Intel Xeon E5-2430V2 2.50 GHz, 15M Cache / 8 GB RDIMM ( 2x4 GB) / 146 GB or 300 GB 15K RPM
Serial-Attach SCSI 6 Gbps 2.5 in Hot plug Hard Drive (QTY 4)/H710 mini Controller (RAID 5
configuration)
l 1 serial, 1Video, 2 USB V2.0, 2 RJ45, 1 ID push button with blue/amber LED.
l 2 USB 2.0, ID push button with blue/amber LED, 1 video, 1 system power on/off button.
l Broadcom 5720 1GbE Dual Port Ethernet NIC with failover and load balancing.
l 2 PCIe slots
o
1x8 slot with x4 bandwidth, 2.0, half-height, half-length
o
1x16 slot with x16 bandwidth, 3.0, full-height, half-length
l Energy Smart – Two hot-plug high-efficient 350W Watts Power Supply.
l Two 110 Volt / 230 Volts Power Cords
l 8 GB RAM 2x4 GB RDIMM 1333 MHz or faster
l SATA DVD-RW Drive
l 2D Matrox®G200 video
2.2.5 Slots configuration
An onboard dual NIC is available for FTE.
- 13 -
Chapter 2 - Planning

Dell PowerEdge R320 Specifications

General

Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR0LS
Processor cache	10 MB
Processor cores	4
Processor model	E5-2403
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2400
Processor socket	LGA 1356 (Socket B2)
Processor codename	Sandy Bridge EN
Motherboard chipset	Intel C600
Processor frequency	1.8 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	45 x 42.5 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	24
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25 GB/s
Maximum internal memory supported by processor	375 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD capacity	1000 GB
HDD interface	Serial ATA
Optical drive type	DVD-RW
Total storage capacity	2000 GB
Maximum storage capacity	16 TB
Number of HDDs installed	2
Memory slots	6x DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	96 GB
Cabling technology	10/100/1000Base-T(X)
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express slots version	3.0
Power supply	350 W
Compatible operating systems	Microsoft Windows Server 2012 \\r Microsoft Windows Server 2012 Essentials\\r Microsoft Windows Server 2008 R2 \\r Novell SUSE Linux Enterprise Server\\r Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Chassis type	Rack (1U)
Processor ARK ID	64615
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Width	- mm
