Dell PowerEdge R320 Planning, Installation And Service Guide

Chapter 2 - Planning
the monitor is connected to the AGP video controller output connector. Note that no touch screen option
is available for this server platform.
2.7.24 Video cable
Correct system startup and operation of the Honeywell-based Dell R320 server platform requires
industry standard VESA DDC interface to the monitor. If either a monitor or video cable that does not
support DDC is attached to the server platform, the display generator defaults to a resolution, which
precludes communication with the system software and stops startup. To determine if a cable is DDC
compatible, ensure that pins 5, 9, and 12 of the HD15 connector are wired. The IS supplied cable
(51196742-200) is DDC compatible.
2.8 Industrial regulatory compliance
The compliance specifications in this section apply to cabinet installations.
WARNING
Honeywell does not claim Safety Compliance or Electromagnetic Compatibility (EMC)
Compliance for system equipment configurations that have not been described in this guide as
standard system configurations. Any equipment configuration other than that described in this
publication decertifies the Safety and EMC compliance of this product.
l Electromagnetic Compatibility
l Safety compliance
2.8.1 Electromagnetic Compatibility
The following table provides the Electromagnetic Compatibility (EMC) specifications (Industrial
Regulatory) for European community.
Element Description
Emissions EN 61326-1:2006 (Industrial Locations, CISPR 11, Class A)
Immunity EN 61326-1:2006 (Industrial Locations)
ATTENTION
The following formula is a proximity guideline, for use of Portable Transceivers (walkie-talkies) in
the frequency range of 80MHz to 1GHz.
D > 0.30*√ {P} (D must be greater than 0.30 multiplied by the square root of P)
D = Distance from equipment, in meters.
P = Power Output of the Portable Transceivers (walkie-talkies), in Watts.
Examples:
P = 10 Watts, D > 0.949 meters
P = 5 Watts, D > 0.671 meters
P = 1 Watt, D > 0.300 meters
- 26 -

Dell PowerEdge R320 Specifications

General

Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR0LS
Processor cache	10 MB
Processor cores	4
Processor model	E5-2403
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2400
Processor socket	LGA 1356 (Socket B2)
Processor codename	Sandy Bridge EN
Motherboard chipset	Intel C600
Processor frequency	1.8 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	45 x 42.5 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	24
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25 GB/s
Maximum internal memory supported by processor	375 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD capacity	1000 GB
HDD interface	Serial ATA
Optical drive type	DVD-RW
Total storage capacity	2000 GB
Maximum storage capacity	16 TB
Number of HDDs installed	2
Memory slots	6x DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	96 GB
Cabling technology	10/100/1000Base-T(X)
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express slots version	3.0
Power supply	350 W
Compatible operating systems	Microsoft Windows Server 2012 \\r Microsoft Windows Server 2012 Essentials\\r Microsoft Windows Server 2008 R2 \\r Novell SUSE Linux Enterprise Server\\r Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Chassis type	Rack (1U)
Processor ARK ID	64615
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Width	- mm
