Dell PowerEdge R410 Technical Guidebook

PowerEdge R410 Technical Guidebook
17
Dell
Table 8. R410 ePPID Descriptions and Locations
Component Description Storage Location
Board
Planar PWA, PLN, SV, DELL, T410 iDRAC FRU
6" x 2.5" Backplane PWA, BKPLN, SV, T410, 2.5SASX6 SEP
6" x 3.5" Backplane PWA, BKPLN, SV, T410, 3.5SASX6 SEP
580 W R410 PSU
PWR SPLY,580W,RDNT, DELTA PSU Microcontroller
PWR SPLY,580W,RDNT,EMERSON PSU Microcontroller
R410 PDB ASSY,PWA,PDB,T410 Microcontroller
Storage Card Description Storage Location
PERC 6/I Adapter ASSY, CRD, PERC6I-ADPT, SAS FRU
PERC 6/E External PWA, CTL, PCIE, SAS, PERC6/E,ADPT FRU
SAS 6/iR integrated PWA, CTL, SAS, SAS6/IR, INTG FRU
6 Power, Thermal, Acoustic
6.1 Power Supplies
The R410 is powered by a non-redundant 480 W power supply (Dell P/N F238K) and redundant 500 W
power supply (Dell P/N F649J).
The power supply has automatic input voltage detection. An auxiliary power-out receptacle is not
provided on this unit.
The power supply in the chassis has been rated as 82%, efficient at 20%, and 100% load, and 85%
efficient at 50% load under 115V AC input line. Redundant power efficiency is 88% at 20% load, 100%
load, 92% efficiency at 50% load under 230V AC input line.
The base system includes a single 480 W power supply. This unit provides power to the PowerEdge
R410 planar, the four internal hard drive bays, and one slim optical disk drive bay. Power is soft-
switched allowing power cycling via a switch on the front of the system enclosure or via software control
(through server management functions). The power system is compatible with industry standards, such
as ACPI and Server 2000.
The VRD is integrated onto the planar and is not field upgradeable. The VRD follows Intel’s VRD11.1
specification. The PowerEdge R410 uses a four-phase design.
6.2 Power Supply Specifications
Single – 480 W power supply
Redundant – 500 W power supply
There are two separate power supply connectors on the planar: an ATX connector (2x12) and a 2x4
connector to provide an additional two pins for +12V. (The ATX connector pin definition is not standard,
and it defined by power rating calculation).
The 2x12 ATX connector provides 3.3V, 5V, 12V, and 12V standby to the system. The 5V standby is
provided to the system via a charge pump from 3.3V standby.

Dell PowerEdge R410 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF9
Processor cache	4 MB
Processor cores	4
Processor model	E5504
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5500
Number of QPI links	2
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	15
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD capacity	250 GB
Optical drive type	DVD-ROM
Total storage capacity	500 GB
Maximum storage capacity	8 TB
Memory slots	8x DIMM
Internal memory	8 GB
Memory clock speed	1066 MHz
Internal memory type	-
Maximum internal memory	128 GB
Memory layout (slots x size)	4 x 2 GB
Maximum graphics card memory	8 MB
Graphics card	G200eW
Networking features	Gigabit Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	480 W
Compatible operating systems	Microsoft SQL Server 2008 R2/Windows Small Business Server 2008/Essential Business Server 2008/Server 2008 SP2, x86/x64/Server 2008 R2/HPC Server 2008; Novell SUSE Linux Enterprise Server; Red Hat Enterprise Linux.
Chassis type	Rack (1U)
Processor ARK ID	40711

Weight and Dimensions

Depth	430 mm
Width	630 mm
Height	40 mm
