Dell PowerEdge R410 Technical Guidebook

PowerEdge R410 Technical Guidebook
23
Dell
• X5550, 2.66G Hz/8M,4C 95W
• E5540, 2.53G Hz/8M,4C 80W
• E5530, 2.40G Hz/8M,4C 80W
• L5520, 2.26G Hz/8M,4C 60W
• L5506, 2.13G Hz/4M,4C 60W
• E5520, 2.26G Hz/8M,4C 80W
• E5506, 2.13G Hz/4M,4C 80W
• E5504, 2.00G Hz/4M,4C 80W
• E5502, 1.86G Hz/4M,2C 80W
Table 14. Supported Processor Descriptions and Features
On-Line Processor Descriptions
Additional Features not Included in
Description
Intel® Xeon® X5570 2.93G Hz, 8M cache, 6.4 GT/s QPI,
Turbo, HT
DDR3 Memory bus speed: up to
1333 MHz
95 W
Intel® Xeon® X5560 2.80G Hz, 8M cache, 6.4 GT/s QPI,
Turbo, HT
DDR3 Memory bus speed: up to
1333 MHz
95 W
Intel® Xeon® X5550 2.66G Hz, 8M cache, 6.4 GT/s QPI,
Turbo, HT
DDR3 Memory bus speed: up to
1333 MHz
95 W
Intel® Xeon® E5540 2.53G Hz, 8M cache, 5.86 GT/s QPI,
Turbo, HT
DDR3 Memory bus speed: up to
1066 MHz
80 W
Intel® Xeon® E5530 2.40G Hz, 8M cache, 5.86 GT/s QPI,
Turbo, HT
DDR3 Memory bus speed: up to
1066 MHz
80 W
Intel® Xeon® E5520 2.26G Hz, 8M cache, 5.86 GT/s QPI,
Turbo, HT
DDR3 Memory bus speed: up to
1066 MHz
80 W
Intel® Xeon® L5520 2.26G Hz, 8M cache, 5.86 GT/s QPI,
Turbo, HT
DDR3 Memory bus speed: up to
1066 MHz
60 W
Intel® Xeon® E5506 2.13G Hz, 4M cache, 4.8 GT/s QPI
DDR3 Memory bus speed: 800 MHz 80 W
Intel® Xeon® L5506 2.13G Hz, 4M cache, 4.8 GT/s QPI
DDR3 Memory bus speed: 800 MHz 60 W
Intel® Xeon® E5504 2.00G Hz, 4M cache, 4.8 GT/s QPI
DDR3 Memory bus speed: 800 MHz 80 W
Intel® Xeon® E5502 1.86G Hz, 4M cache, 4.8 GT/s QPI
DDR3 Memory bus speed: 800 MHz 80 W
• QPI – Quick Path Interconnect is a point-to-point processor interconnect developed by Intel to compete with AMD's
Hyper Transport; it is defined using Gigatranfers (GT/s) per second referring to a number of data transfers or
operations
• Turbo – Feature that increases the speed of the processor on demand (from OS) if the CPU is operating below
power/thermal specifications
• DDR-3 Memory bus speed: 800 MHz, 1066 MHz, or 1333 MHz
• HT – Intel Hyper-threading technology
8.3 Processor Configurations
R410 operates in single processor or dual processors. However, because the memory controller is
embedded in the processor when only one processor is installed in the system, it supports 4 DIMMs,
min. 1 GB and max 32 GB. When two processors are installed in the system, it supports 8 DIMMs, min.
2 GB and max 64 GB.

Dell PowerEdge R410 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF9
Processor cache	4 MB
Processor cores	4
Processor model	E5504
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5500
Number of QPI links	2
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	15
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD capacity	250 GB
Optical drive type	DVD-ROM
Total storage capacity	500 GB
Maximum storage capacity	8 TB
Memory slots	8x DIMM
Internal memory	8 GB
Memory clock speed	1066 MHz
Internal memory type	-
Maximum internal memory	128 GB
Memory layout (slots x size)	4 x 2 GB
Maximum graphics card memory	8 MB
Graphics card	G200eW
Networking features	Gigabit Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	480 W
Compatible operating systems	Microsoft SQL Server 2008 R2/Windows Small Business Server 2008/Essential Business Server 2008/Server 2008 SP2, x86/x64/Server 2008 R2/HPC Server 2008; Novell SUSE Linux Enterprise Server; Red Hat Enterprise Linux.
Chassis type	Rack (1U)
Processor ARK ID	40711

Weight and Dimensions

Depth	430 mm
Width	630 mm
Height	40 mm
