Dell PowerEdge R410 Technical Guidebook

PowerEdge R410 Technical Guidebook
40
Dell
20.3 Embedded Server Management
The PowerEdge R410 implements circuitry for the next generation of Embedded Server Management.
It is Intelligent Platform Management Interface (IPMI) v2.0 compliant. The optional iDRAC (Integrated
Dell Remote Access Controller) is responsible for acting as an interface between the host system and
its management software and the periphery devices. These periphery devices consist of the PSUs, the
storage backplane, integrated SAS HBA or PERC 6/I, and control panel with display.
The optional upgrade to iDRAC6 provides features for managing the server remotely or in data center
lights-out environments.
Advanced iDRAC features require the installation of the optional iDRAC6 Enterprise card.
20.4 Lifecycle Controller and Unified Server Configurator
Embedded management is comprised of several interdependent pieces:
• Lifecycle Controller
• Unified Server Configurator
• iDRAC6
• vFlash
Lifecycle controller powers the embedded management features. It is integrated and tamperproof
storage for system-management tools and enablement utilities (firmware, drivers, etc.). It is flash
partitioned to support multiple, future-use cases.
Dell Unified Server Configurator (USC) is a local 1:1 graphical user interface embedded on Lifecycle
Controller that aids in local server provisioning in a pre-OS environment. For servers with iDRAC
Express, the Lifecycle Controller offers OS install, platform updates, platform configuration, and
diagnostics capabilities. For servers without iDRAC Express, this utility has limited functionality and
offers OS install and diagnostics capabilities only.
To access the Unified Server Configurator, press the <F10> key within 10 seconds of the Dell logo’s
appearance during the system boot process. Current functionality enabled by the Unified Server
Configurator includes:
Table 23. Unified Server Configurator Features and Description
Feature Description
Faster O/S Installation Drivers and the installation utility are embedded on
system, so no need to scour DELL.COM
Faster System Updates Integration with Dell support automatically directed to
latest versions of the Unified Server Configurator,
iDRAC, RAID, BIOS, NIC, and Power Supply
Update Rollback Ability to recover to previous “known good state” for all
updatable components
More Comprehensive Diagnostics
Diagnostic utilities are embedded on system
Simplified Hardware Configuration
Detects RAID controller and allows user to configure
virtual disk and choose virtual disk as boot device,
eliminating the need to launch a separate utility. Also
provides configuration for iDRAC, BIOS, and NIC/LOM.

Dell PowerEdge R410 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF9
Processor cache	4 MB
Processor cores	4
Processor model	E5504
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5500
Number of QPI links	2
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	15
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD capacity	250 GB
Optical drive type	DVD-ROM
Total storage capacity	500 GB
Maximum storage capacity	8 TB
Memory slots	8x DIMM
Internal memory	8 GB
Memory clock speed	1066 MHz
Internal memory type	-
Maximum internal memory	128 GB
Memory layout (slots x size)	4 x 2 GB
Maximum graphics card memory	8 MB
Graphics card	G200eW
Networking features	Gigabit Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	480 W
Compatible operating systems	Microsoft SQL Server 2008 R2/Windows Small Business Server 2008/Essential Business Server 2008/Server 2008 SP2, x86/x64/Server 2008 R2/HPC Server 2008; Novell SUSE Linux Enterprise Server; Red Hat Enterprise Linux.
Chassis type	Rack (1U)
Processor ARK ID	40711

Weight and Dimensions

Depth	430 mm
Width	630 mm
Height	40 mm
