Dell PowerEdge R410 Technical Guidebook

PowerEdge R410 Technical Guidebook
3
Dell
2 New Technologies
2.1 Overview
• Intel 5500 chipset and Intel Xeon 5500 series processor (new Intel architecture)
• Memory RAS feature (mirroring)
• iDRAC6 (new Dell server remote management controller)
• Virtualization (support various virtualization applications)
• SSD advantage (support SSD drives)
3 System Overview
3.1 Overview
The PowerEdge R410 delivers the right combination of computing power and redundancy in an ultra-
dense chassis. It is positioned to compete against HP’s DL160/DL165, and IBM’s x3450/x3455. The
PowerEdge R410 provides:
• Outstanding price and feature set combination
• Industry leading features configurability without burdening the entry configuration price
• Industry leading server management with LifeCycle Controller available via optional iDRAC
Express or iDRAC Enterprise
• Security features with TPM, internal USB, and IPv6
• Industry leading storage expandability and $/GB with 4 x 3.5”/2.5” HDD, cabled and hot-swap
• Industry leading serviceability and diagnostics with optional interactive LCD
• Industry leading chassis depth of only 24” in its class for SMB closets, shallow racks, mobile
server enclosures, wall server enclosures, A/V racks and legacy server racks
3.2 Product Features Summary
Table 2. PowerEdge R410 Features and Descriptions
Features Descriptions
Chipset Intel® 5500 chipset (5500 24 + ICH10R)
CPU Intel Xeon® 5500 series processor (Intel 5500 EP)
DIMM 4+4 DDR3
Unbuffered with ECC or Registered with ECC
1333/1066/800 MHz
Memory
Modules
1 GB UDIMM/RDIMM
2 GB UDIMM/RDIMM
4 GB RDIMM
8 GB RDIMM
TPM TPM
TCM/NO TPM
Expansion Slots 1 PCI slots
Slot 1: PCIe x16 (True x16, Gen2), half length
Slot 2: Propriety for SAS 6/iR Modular card only

Dell PowerEdge R410 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF9
Processor cache	4 MB
Processor cores	4
Processor model	E5504
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5500
Number of QPI links	2
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	15
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD capacity	250 GB
Optical drive type	DVD-ROM
Total storage capacity	500 GB
Maximum storage capacity	8 TB
Memory slots	8x DIMM
Internal memory	8 GB
Memory clock speed	1066 MHz
Internal memory type	-
Maximum internal memory	128 GB
Memory layout (slots x size)	4 x 2 GB
Maximum graphics card memory	8 MB
Graphics card	G200eW
Networking features	Gigabit Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	480 W
Compatible operating systems	Microsoft SQL Server 2008 R2/Windows Small Business Server 2008/Essential Business Server 2008/Server 2008 SP2, x86/x64/Server 2008 R2/HPC Server 2008; Novell SUSE Linux Enterprise Server; Red Hat Enterprise Linux.
Chassis type	Rack (1U)
Processor ARK ID	40711

Weight and Dimensions

Depth	430 mm
Width	630 mm
Height	40 mm
