Dell PowerEdge R410 Technical Guidebook

PowerEdge R410 Technical Guidebook
1
Dell
1 Product Comparison
1.1 Overview
The PowerEdge R410 is Dell’s entry 2-socket 1U rack server that supports the latest Intel chipset and
processors. With the new Intel architecture, the memory controller is built in the processor and each
processor in PowerEdge R410 supports 4 DIMMs. If two processors are installed, it supports 8 DIMMs
max. Dell introduces four 3.5” hard drive bays to maximize the storage capacity in this product space.
R410 also offers state-of-art features, including: hot-swap hard drive, redundant power supply, 2.5”
SAS or SSD, and quad pack LED or active LCD for diagnostic. The PowerEdge R410 also supports
Dell’s latest remote server management controller and iDRAC6, to easily manage the server.
Table 1. Comparison of R410 to SC1435 and R610
Feature/Spec R410 SC1435 (Predecessors)
R610
(Next level up)
Processor
Two-Socket Intel® Xeon®
processor 5500 series
AMD Opteron 2XXX
series
Two-Socket Intel Xeon
processor 5500 series
Front Side Bus
IQP at 6.4 GT/s 1 GBz HyperTransport IQP at 6.4 GT/s
# Processors
1 to 2 1 or 2 1 to 2
# Cores
Dual or Quad Dual or Quad Dual or Quad
L2/L3 Cache
4 MB or 8 MB 4 MB or 8 MB
Chipset
Intel® 5500 chipset HT2100 + HT1000 Intel® 5520 chipset
DIMMs
4+4 DDR3
Unbuffered with ECC or
Registered with ECC
1333/1066/800M Hz
8 DDR2
Registered with ECC
667 MHz
6+6 DDR3
Unbuffered with ECC or
Registered with ECC
1333/1066/800 MHz
Min/Max RAM
1 GB/64 GB 512 MB/32 GB 1 GB/96 GB
HD Bays
4 x 3.5”
Optional Hot-Swap
Support 2.5" HDDs via
Hot-Swap tray
2x 3.5”
6 x 2.5” Hot-Swap
HD Types
Default SATA. Optional
SAS and SSD via add-in
controller
Default SATA. Optional
SAS via add-in controller
SAS or SSD
Ext Drive Bay(s)
1 for slim ODD 1 for slim ODD 1 for slim ODD
Embedded HD
Controller
Chipset based SATA Chipset based SATA SAS 6/iR
Optional Storage
Controller
NON-RAID:
SAS 5/E
LSI 2032 (For TBU only)
RAID:
SAS 6/iR Modular
PERC 6/i, PERC 6/E
SAS 5/iR
SAS 6/iR
NON-RAID:
SAS 5/E
LSI 2032 (For TBU only)
RAID:
SAS 6/iR (Default)
PERC 6/i, PERC 6/E

Dell PowerEdge R410 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF9
Processor cache	4 MB
Processor cores	4
Processor model	E5504
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5500
Number of QPI links	2
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	15
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD capacity	250 GB
Optical drive type	DVD-ROM
Total storage capacity	500 GB
Maximum storage capacity	8 TB
Memory slots	8x DIMM
Internal memory	8 GB
Memory clock speed	1066 MHz
Internal memory type	-
Maximum internal memory	128 GB
Memory layout (slots x size)	4 x 2 GB
Maximum graphics card memory	8 MB
Graphics card	G200eW
Networking features	Gigabit Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	480 W
Compatible operating systems	Microsoft SQL Server 2008 R2/Windows Small Business Server 2008/Essential Business Server 2008/Server 2008 SP2, x86/x64/Server 2008 R2/HPC Server 2008; Novell SUSE Linux Enterprise Server; Red Hat Enterprise Linux.
Chassis type	Rack (1U)
Processor ARK ID	40711

Weight and Dimensions

Depth	430 mm
Width	630 mm
Height	40 mm
