4 Mechanical
4.1 Chassis Description
The Dell™ PowerEdge™ R910 fits in a rack mount 4U chassis. The R910 chassis brings some new
features over previous generations, including:
 DIMMs on memory risers
 Updated industrial design including a new LCD, bezel, and hard drive carriers
 Toolless rack latches
 Pull-out tray for Express Service Tag and customer labels
 Support for persistent storage (internal USB and SD card slots and external SD card slot)
 Updated, easier power supply removal process
4.2 Dimensions and Weight
The R910 weight with maximum configuration is 47.60 kg (105 lb). Weight empty is 26.31 kg (58 lb).
Xa
(width
with rack
latches)
Xb
(width
without
rack
latches)
Y
(Height)
Za
(depth
with
bezel)
Za
(depth
without
bezel)
Zb
(depth
without
power
supply and
bezel)
Zc
(depth
with
power
supply)
482.4mm
422.0mm
172.6mm
35.0mm
20.4mm
699.0mm
753.0mm
Figure 1. Dimensions

Dell PowerEdge R910 Specifications

General

Processor	Up to four Intel Xeon 7500 series processors
Form Factor	4U Rack Server
Storage	Up to 16 x 2.5" SAS, SATA, or SSD drives
RAID Controller	PERC H700, PERC H800
Network	Embedded Broadcom 5709c Gigabit Ethernet
Power Supply	Redundant 1100W power supplies
Expansion Slots	10 PCIe slots
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Memory	Up to 1TB DDR3 (64 DIMM slots)
