RAID 1 set is SSD, RAID 5 set is
SAS
C15
MSSR1R10-X
Integrated SSD/SAS RAID
1/RAID 10 (PERC H700)
RAID 1 set is SSD, RAID 10 set
is SAS
X
X
2+4
2+14
C16
MSSR1R50-X
Integrated SSD/SAS RAID
1/RAID 50 (PERC H700)
RAID 1 set is SSD, RAID 50 set
is SAS
X
X
2+6
2+14
C17
MSSR10R50-
X
Integrated SSD/SAS RAID
10/RAID 50 (PERC H700)
RAID10 set is SSD, RAID 50 set
is SAS
X
X
4+6
8+8
Additional RAID requirements are listed as follows:
 All connection types are backplane.
 X indicates not supported.
 The x16 backplane is supported only by PERC H700.
 The x4 backplane is supported by both PERC H200 and PERC H700.
 SATA drives are supported only on the x4 backplane. A maximum of only one SATA drive is
allowed and is only in the C1 configuration.
12.6 Storage Controllers
12.6.1 PERC H200
The PERC H200 integrated HBA is a SAS 2.0 6Gb native PCIe half-length half-height expansion card
that plugs into a dedicated x8 storage slot. It supports RAID 0, RAID 1, RAID 10 and non-RAID hard
drive configurations. It incorporates one four-channel mini-SAS internal connector (SFF8087) for
connection to internal x4 2.5” drive backplane. Since there are a maximum of up to 4-drives, the
second mini-SAS connector from H200 to the backplane would not get used. PERC H200 will only be
supported when the 4-drive 2.5” backplane is present on R910.
12.6.2 PERC H700
For customers who need a more advanced hardware RAID solution, the PERC H700 (formerly known as
PERC 7/iR) is an option. The PERC H700 is a SAS 2.0 6Gb half-length PCIe x8 expansion card that uses
the LSI 2108 ROC (RAID on Chip) processor running at 800MT/s with a PCI Express host interface and
DDR2 memory. It supports 512MB cache that is battery backed. It supports RAID 0, RAID 1, RAID 5,
RAID 6, RAID 50, RAID 60 and PRL-11 hard drive configurations. It incorporates two four-channel
mini-SAS connectors (SFF8087) for connection to internal x4 or x16 2.5” drive backplanes. The second
mini-SAS connectors would not get used when connecting PERC H700 to the x4 internal backplane.

Dell PowerEdge R910 Specifications

General

Processor	Up to four Intel Xeon 7500 series processors
Form Factor	4U Rack Server
Storage	Up to 16 x 2.5" SAS, SATA, or SSD drives
RAID Controller	PERC H700, PERC H800
Network	Embedded Broadcom 5709c Gigabit Ethernet
Power Supply	Redundant 1100W power supplies
Expansion Slots	10 PCIe slots
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Memory	Up to 1TB DDR3 (64 DIMM slots)
